Contact closures, relays, Cue servers, DMX decoder units, din rails… if you’re a conceptual designer, you’re probably not too interested in what those mean, but when implemented through a thoughtful electrical engineering process, these items can add a whole new element of fluctuation to your spaces.

Imagine synchronizing the vertical movement of an elevator with a lighting effect that “speaks” to the waiting patrons. At the renovation of 1828 L Street in Washington, D.C., lighting designers MCLA and architects DEP Designs envisioned a full scale elevator lantern that capitalized on the dynamics of time and movement (fitting for an elevator lobby). The elevator call lanterns take on a modern architecture with full height panels of backlit glass. Goodbye, standard call buttons!

Standard Elevator Indicator Buttons - small scale, appear "additive" to the architecture (Image Credit: robinsonsmay)

Re-designed Backlit Lanterns - large scale, integral to the architecture

The design intent was to have the elevator lanterns illuminated at a dim level at all times. When the elevators descend to the main lobby at the first floor, the lanterns slowly brighten up to 100%, signifying the arrival of the elevator cab.  Pretty cool visual reinforcement of movement!

Custom controls by GPI sync the elevator control system with our Flat-Lite™ LED panels

Only one of the elevators descends to the basement; the designers wanted the lantern at this elevator to illuminate in a red color. At this area, GPI designed a dual-illumination red and white LED panel to backlight the glass. The colored and white settings were engineered to be controlled independently. When the cab is above ground, the lantern remains white like the others. The relay to the red LED string only fires when the elevator drops to the basement level, at which time the LED panel changes to its red hue.

Flat-Lite™ LED panel on white and red settings

This is just one job that goes to show the value of integration when it comes to backlit features. As you’ll often hear us advocate, to have a truly well-executed backlit feature, it’s much more about the LED panels themselves. In this case, the LED panels were properly designed to both seamlessly illuminate the surface and interface with the existing elevator control system, for a lighting effect that strengthens the architecture. The challenges of the project were perfectly suited for our team and we’re looking forward to publishing the final installation photographs soon!

In the overview blog post, The 10 Benefits of Lighting Control for Greener, Smarter Building Design, Bill Trammel of the Lighting Control Pros blog outlines the main benefits of implementing lighting control into architectural design.  This blog post provided a great overview of points that can both enlighten designers AND provide relevant data to assist them in convincing their clients (building owners and developers).

Architects and designers probably understand this from multiple angles, many of which Bill Trammel touched upon, but the perceived benefits of lighting control really depends on who's listening, right? Here's GPI's case for implementing controllable lighting systems, in plain language that building owners might connect with:

You wouldn't buy a Mercedes Benz without purchasing the automatic window upgrade, would you?

High-end lighting systems are implemented through an intense detailed process that involve collaboration and engineering. The upgrade, offering real convenience, is a natural extension of the baseline system.  Additional cost, yes, but you will probably never regret the upgrade.

(Notice we are using the Benz as an example for the owner? If we were talking to you, Ms./Mr. Designer, we would have said "1999 Volvo". Yep, we know you're overworked and underpaid.)

Let's make sure that everyone is satisfied with these lighting levels on-site after all is said and done.

You can quantify this LED fixture with test data all day long, but lighting levels are subjective. Avoid the costly mistake of implementing non-controllable lighting, which results in tearing down finishes to modify or remove fixtures. (Headaches, schedule extension, added cost)

Dimming control provides the opportunity for lighting designers and building owners to "tune" the brightness of fixtures based on many variables: desired brightness levels, ambient lighting conditions, subjective perception.

During the building walk-through and commissioning process, dimming control will prove to be a crucial tool in fine tuning all of the systems into a harmonious composition.

You like to see your huge building investment pay off over the years, don't you?

As Bill Trammel succinctly put it: "from a purely bottom-line standpoint, dimming reduces monthly overhead costs".  Dimming control reduces energy costs, increases occupant comfort, and can contribute to employee productivity.  Building owners see every project as an investment; quantifying this can help to justify the increased upfront costs.

And last but not least... controllable lighting systems can contribute to LEED certification, and let's face it - LEED is a great marketing/publicity tool for building owners.

--> The bottom line: when your lighting fixture manufacturers have dimming capability available and the budget allows, take them.  Just like when you're caught driving that new Benz (ehh, 1999 Volvo) in a rainstorm, you won't regret purchasing the automatic roll-up window option.

Project Update: LED Light Panels at AED Idea Center Installed, Glass Panels Evenly Backlit

Backlit Glass Columns by GPI | AED Idea Center | Washington, D.C.

Architect: Studio 27 Architecture

Lighting Designer: MCLA

Application: Backlit frosted glass at eight columns

Products: GPI Infuse™ Flat-Lite™ LED Panels at 3500K lighting temperature

Integration: Diffuser films to hide lamp image and disguise hot spots, GPI Infuse™ Custom Power/Dimming Packs that communicate with Lutron 5000 Graphic Eye to balance brightness between large and small panels

This is a rough progress image from the field.  Check back for completed photographs when the dimming interface is completed!

(Blog Update 1/16/11: see the completed photographs)

Project Update: LED Panels Wired and Installed, Glass is Evenly Backlit

Backlit Glass Columns by GPI | AED Idea Center | Washington, D.C.

Architect: Studio 27 Architecture

Lighting Designer: MCLA

Application: Backlit frosted glass at eight columns

Products: Frosted glass panels, GPI LED Panels at 3500 K, GPI Custom Dimming Packs that communicate with Lutron 5000 Graphic Eye

Integration: Diffuser films to hide lamp image and disguise hot spots, GPI Dimming Packs to balance brightness between large and small panels

Above image indicates construction progress from the field.  Check back for completed photographs when the dimming interface and surrounding finishes are complete!

Acronyms galore.  The letters "L", "E", and "D" on my keyboard are going to be worn out after this blog post!

Lighting systems typically constitute the highest energy use in commercial buildings. The USGBC (United States Green Building Council) has recognized the energy savings potential in general lighting systems, and LED lighting systems can be a significant contributor to obtaining Leadership in Energy and Environmental Design (LEED) certification for a new building. LED lighting systems can contribute to LEED certification in at least three areas: Energy and Atmosphere, Indoor Environmental Quality, and Innovation and Design Process.

Energy and Atmosphere (EA) 35 possible points

Prerequisite 1: Fundamental Conditioning of Building Energy Systems

Prerequisite 2: Minimum Energy Performance

Credit 1: Optimization of Energy Performance (worth 1 to 19 points) is the primary area where LED lighting can have an impact. The proposed building design must demonstrate improved performance as compared to baseline criteria.   The greater the performance from baseline, the more points are awarded.

-Reduced carbon emissions (as compared to incandescent lighting)
-Low operating temperatures reduce heat dissipation into spaces, cutting the strain on the HVAC system and ultimately saving air conditioning costs
-Compatibility with photovoltaics
-Minimize energy usage by integrating LED lighting systems into Lutron or other building management system

Indoor Environmental Quality (IEQ)

Credit 6.1: Controllability of Systems- Lighting
Control of the lighting system by individual occupants or specific groups in multi-occupant spaces can potentially earn 1 point toward LEED certification. LED luminaires provide the opportunity to work as part of a lighting control plan/central building management system. They provide light instantaneously once power is applied, requiring no warm up time. LED lighting systems can also be dimmed to provide variable light output depending upon the needs of the occupant. The efficacy of LEDs efficacy actually increases when they are dimmed due to lower junction temperatures. Continuous, non-stepped dimming provides occupant comfort and increases efficiency.

Innovation and Design Process (ID) worth from 1 to 5 points

Credit 1: The utilization of innovative products and processes may earn between 1 and 4 points toward LEED certification. As LED lighting systems for general lighting represent new, innovative technology, they may qualify for LEED certification credit. LEED does not award this credit if a product is already obtaining points in another category, so design teams must choose where the most impact can be made and pursue credit(s) accordingly.

Other benefits of LED lighting:
LED (light emitting diode) lighting systems are not only environmentally sustainable, but can be cost efficient as well. Even if your building isn’t striving for LEED certification, there are numerous benefits that are attractive to designers and building owners. While the upfront costs of LED lighting systems and dimming capability are often greater than traditional lighting methods, the life cycle and can even add value to the property in the long run.

-Fewer building materials required
-Reduced operational costs for electricity and maintenance
-No hazardous materials or wastes (lead and mercury free)
-Longer lifespan= less waste for landfills
-Simpler installation
-Possible commercial building tax deductions

More information on GPI's FLAT-Lite™ LED lighting system complete with commercial capacity power supplies and dimming options.

The above summary is based on LEED v3 which was released by the USGBC in April 2009 for LEED New Construction and Major Renovations (NC).  This summary does not include the potential of LED lighting to earn points for exterior applications and light pollution reduction.
